Two valves manifold for pressure instrument - BM2V-2
-BM2V-2
Two valves manifold for pressure instrument - BM2V-2
Technical specifications
- Bar stock body with outside screwed bonnet
- Process and instrument connections: 1/2” NPT-F ANSI B1.20.1
- Standard drain connections: 1/4” NPT-F ANSI B1.20.1
- N. 2 Bore for mounting on bracket
- Nominal operating pressure: SERIE 3000 - 6000 / 210 - 420 Kg/cmq
- Packing material PTFE as std. max temperature 180°C. For temperature until 500°C special packing free asbestos.
- Orifice size 4 mm
- Material: AISI 316.
Other material on request
